Pressure gauge diameter 63mm 0-20-40-60 1/4" BSP bottom connection
£29.50
Pressure gauge diameter 63mm 0-20-40-60 1/4" BSP bottom connection
| Part number | MA632060E |
|---|---|
| EAN | |
| Unit | Each |
| Brand | ET |
| Product category | Pressure gauge |
| Mounting type | Connection bottom |
| Indicator type | Analogue |
| Min. pressure | 0 BAR |
| Max. pressure | 20 BAR |
| Housing outside diameter | 63 mm |
| Connection thread type | BSP |
| Connection thread diameter | 1/4 Inch |
| Material housing | Stainless steel |
| Connection material | Stainless steel |
| Class | 1.6 |
| Filled | Yes |
| Filled with | Glycerine |
| Min. working temperature | -10 °C |
| Max. working temperature | 60 °C |
| Material of glass | Laminate |
| Series | 7221 |
